Posts made by chuanzhen

@ferdinand Thanks for your help!

Hi,
I want to refresh the dialog when switching documents. I tried to use the following code, but it seems that this cannot be achieved .
When I switch documents, it seems that I only receive type==c4d.MSG_COMMANDINFORMATION

code:

    def Message(self, type, data):
        print("msg type:{}".format(type))
        print("data:{}".format(data))
        if type == c4d.MSG_DOCUMENTINFO:
            if data['type'] == c4d.MSG_DOCUMENTINFO_TYPE_SETACTIVE:
                print("doc Change!")
        return True

Thanks for any help!

@manuel Thanks for your help!

Hi,
i want to Copy all info of one Object to other Object.Use source.CopyTo(aim), But object aim is dead after CopyTo().
My purpose is to copy all the information of an object except the basic information to another object, so after CopyTo(), I want to use the backup information to restore the basic information of aim, but the object is dead and an exception will be thrown

this is code:

import c4d
from c4d import gui

def main():
    source,aim = doc.GetActiveObjects(2)
    doc.StartUndo()
    #backup basic properties
    info_list = []
    description = aim.GetDescription(c4d.DESCFLAGS_DESC_NONE)
    did_list = [c4d.DescID(c4d.DescLevel(110050, 1, 110050)),
                c4d.DescID(c4d.DescLevel(1041666, 1, 110050))]
    for bc, paramid, groupid in description:
        if groupid in did_list:
            if aim[paramid]:
                info_list.append((paramid, aim[paramid]))
    doc.AddUndo(c4d.UNDOTYPE_CHANGE,aim)
    source.CopyTo(aim, c4d.COPYFLAGS_NO_BRANCHES|c4d.COPYFLAGS_NO_MATERIALPREVIEW|c4d.COPYFLAGS_NO_BITS)
    #restore  basic properties
    for info in info_list:
        aim[info[0]] = info[1]

    doc.EndUndo()
    c4d.EventAdd()
# Execute main()
if __name__=='__main__':
    main()

Thanks for any help!

@ferdinand Thanks you for your help！

@ferdinand Thanks

pic 2 : Close Save, the regluar image Save must be not save

pic 3:Open Save, the regluar image Save save or not save depends on itself

@ferdinand Thanks,MyRenderSetting[c4d.RDATA_SAVEIMAGE] = True I use this method in my code, it can achieve the purpose of not save image, but I am wondering if I can access the state of the Save element in pic1, so that when I activate my renderSetting, I do not click Go in and check the status of [c4d.RDATA_SAVEIMAGE], you can also directly know whether it is a saved state or an unsaved state during the current rendersetting

@m_adam Thanks for your help，great work!

@m_adam Thanks!

Hi,
Use RenderData how to change "Save" state!
Thanks for any help!

pic1

This is the sample code, I tried to dynamically create the element inside the group to achieve, the picture is not drawn completely as expected：

import c4d
import os
import sys
from c4d import gui,bitmaps,plugins,utils,modules,storage


PLUGIN_ID = 10000000 #only for test



GROUP_SCROLL = 1100
USEEAREA_GROUP = 1102
USERAREA = 1101

ADD_BUTTON = 1200

class PreViewArea(gui.GeUserArea):
    bmp = None


    def DrawMsg(self,x1, y1, x2, y2, msg):
        self.OffScreenOn()
        self.SetClippingRegion(x1, y1, x2, y2)
        BG_colorDict = self.GetColorRGB(c4d.COLOR_BG)
        BG_color = c4d.Vector(BG_colorDict['r'], BG_colorDict['g'], BG_colorDict['b']) / 255.0
        self.DrawSetPen(BG_color)
        self.DrawRectangle(x1, y1, x2, y2)

        if self.bmp:
            width = self.bmp.GetBw()
            height = self.bmp.GetBh()
            self.DrawBitmap(self.bmp, 0, 0, width, height, 0, 0, width, height, c4d.BMP_NORMAL)

def dynamic_Group(dialog,ua):
    dialog.LayoutFlushGroup(USEEAREA_GROUP)

    if ua.bmp:
        width = ua.bmp.GetBw()
        height = ua.bmp.GetBh()
    else:
        width,height = 0,0
    dialog.AddUserArea(USERAREA, c4d.BFH_SCALE | c4d.BFV_SCALE,width,height)
    dialog.AttachUserArea(ua, USERAREA)
    dialog.LayoutChanged(USEEAREA_GROUP)

class S_Lib_Dialog(gui.GeDialog):
    ua = PreViewArea()


    def CreateLayout(self):
        self.SetTitle("test")
        self.ScrollGroupBegin(PLUGIN_ID, c4d.BFH_SCALEFIT | c4d.BFV_SCALEFIT, c4d.SCROLLGROUP_HORIZ | c4d.SCROLLGROUP_VERT)
        self.GroupBegin(USEEAREA_GROUP,c4d.BFH_LEFT | c4d.BFV_TOP,1,1)
        self.GroupBorder(c4d.BORDER_ACTIVE_1)
        self.AddUserArea(USERAREA, c4d.BFH_SCALEFIT | c4d.BFV_SCALEFIT)
        self.AttachUserArea(self.ua, USERAREA)
        self.GroupEnd()

        self.GroupEnd()
        self.AddButton(ADD_BUTTON,c4d.BFH_SCALEFIT,150,30,"Load image")


        return True

    def Command(self, id, msg):
        if id == ADD_BUTTON:
            path = storage.LoadDialog(type=c4d.FILESELECTTYPE_IMAGES)
            if path:
                bmp = bitmaps.BaseBitmap()
                result,ismovie = bmp.InitWith(path)
                if result == c4d.IMAGERESULT_OK:
                    self.ua.bmp = bmp
                    dynamic_Group(self, self.ua)
                    self.ua.Redraw()
                else:
                    print("Load image Fail")
            else:
                print("Not select image")



            return True

        return True






class S_Lib(plugins.CommandData):

    dialog = None

    def Execute(self,doc):
        # create the dialog
        if self.dialog is None:
            self.dialog = S_Lib_Dialog()

        return self.dialog.Open(dlgtype=c4d.DLG_TYPE_ASYNC, pluginid=PLUGIN_ID, defaultw=800, defaulth=400)

    def RestoreLayout(self, sec_ref):
        # manage nonmodal dialog
        if self.dialog is None:
            self.dialog = S_Lib_Dialog()

        return self.dialog.Restore(pluginid=PLUGIN_ID, secret=sec_ref)


# Execute main()
if __name__=='__main__':
    path, fn = os.path.split(__file__)
    plugins.RegisterCommandPlugin(id=PLUGIN_ID,
                                  str="test",
                                  info=0,
                                  help="",
                                  dat=S_Lib(),
                                  icon=None)

Hi,
In my scrollgroup, I created a UserArea to draw pictures, but the size of the pictures to be drawn is dynamic,
that is to say, when the dialog is opened, different pictures are loaded and switching displayed by clicking button . When image size changing, expect the scrolling gui component to always be correct.
(The picture drawn in the UserArea is 1:1, such as a 1280 * 720 picture file, the size in UserArea drawed also 1280 * 720).

When I created it, the size of the UserArea could not automatically adapt to the image size, which caused the gui component of the scroll group to not work as expected.

After reading these two posts(Scrolling in UA/Scaling a GeUserArea in a ScrollGroup), I still can't achieve this goal! Thanks for any help!

@m_magalhaes Thanks for the detailed explanation as to why it crashed！

Hey @ferdinand ,
Using the following code, the crash will also occur

test commanddata plugins code

import c4d
import os
import sys
from c4d import gui,bitmaps,plugins,utils,modules,storage


PLUGIN_ID = 10000000 #only for test
SUB_DIALOG_ID = 1000001



SUB_DIALOG_GONE = 5000
SUB_DIALOG_GONE_NAMETEXT = 5001
SUB_DIALOG_GONE_NAME = 5002

SUB_DIALOG_GONE_ANIGROUP = 5003
SUB_DIALOG_GONE_ANIGROUP_ALLRANGE = 5004
SUB_DIALOG_GONE_ANIGROUP_PRERANGE = 5005


SUB_DIALOG_GTWO = 5010
SUB_DIALOG_GTWO_EDITIMAGE = 5011
SUB_DIALOG_GTWO_CUTIMAGE = 5012

SUB_DIALOG_IMAGE = 5020
SUB_DIALOG_SAVE = 5021

#active tool
def UseSreenShot(active=False,path=None,name=None,size=None,cutimage=False,child_path="image"):
    tool_id = 1000010

    doc = c4d.documents.GetActiveDocument()
    tool = plugins.FindPlugin(tool_id, c4d.PLUGINTYPE_TOOL)
    data = plugins.GetToolData(doc, tool_id)

    if active:
        doc.SetAction(tool_id)
        #c4d.CallCommand(1059888)  # S_ScreenShot
    if path:
        data[1] = os.path.join(path,child_path)
    if name:
        data[2] = name
    if size:
        data[3] = size

    if cutimage:
        tool.Message(tool_id)  #
    else:
        tool.Message(tool_id) #



#
class S_Add_Dialog(gui.GeDialog):
    name = None
    path = None
    size = None
    mode = 0
    ua = None


    def CreateLayout(self):
        if self.mode == 3:
            self.SetTitle("Setting")
        else:
            self.SetTitle("New ")

        self.GroupBegin(SUB_DIALOG_GONE,c4d.BFH_SCALEFIT,3,1)
        self.AddStaticText(SUB_DIALOG_GONE_NAMETEXT,c4d.BFH_LEFT,100,10,"Name:")
        self.AddEditText(SUB_DIALOG_GONE_NAME,c4d.BFH_SCALEFIT,150,20)
        if self.mode == 1:
            #
            self.AddRadioGroup(SUB_DIALOG_GONE_ANIGROUP,c4d.BFH_RIGHT,2,1)
            self.AddChild(SUB_DIALOG_GONE_ANIGROUP,SUB_DIALOG_GONE_ANIGROUP_ALLRANGE,"All Range")
            self.AddChild(SUB_DIALOG_GONE_ANIGROUP, SUB_DIALOG_GONE_ANIGROUP_PRERANGE, "Preview Range")
            self.SetInt32(SUB_DIALOG_GONE_ANIGROUP,SUB_DIALOG_GONE_ANIGROUP_ALLRANGE)

        self.GroupEnd()
        self.GroupBegin(SUB_DIALOG_GTWO,c4d.BFH_SCALEFIT,1,1)
        self.AddButton(SUB_DIALOG_GTWO_CUTIMAGE,c4d.BFH_SCALEFIT,150,30,"Get Image")
        #self.AddButton(SUB_DIALOG_GTWO_CUTIMAGE, c4d.BFH_SCALEFIT, 150, 30, "Get Image")
        self.GroupEnd()

        #self.AddUserArea(SUB_DIALOG_IMAGE,c4d.BFH_SCALEFIT | c4d.BFV_SCALEFIT,100,100)
        #self.ua = UserArea_forAdd()
        #self.AttachUserArea(self.ua,SUB_DIALOG_IMAGE)
        self.AddButton(SUB_DIALOG_SAVE, c4d.BFH_SCALEFIT, 150, 30, "Save")


        return True
    def Command(self, id, msg):
        return True


class S_Lib_Dialog(gui.GeDialog):

    sub_dialog = S_Add_Dialog()

    def CreateLayout(self):
        self.SetTitle("test")

        self.AddButton(1001,c4d.BFH_SCALEFIT | c4d.BFV_SCALEFIT,150,30,"test")

        return True

    def Command(self, id, msg):
        if id == 1001:
            #SUB_DIALOG_ID = 1000001
            UseSreenShot(active=True, path='AAAA', name='BBB')  # active tool,and send message
            self.sub_dialog.Open(dlgtype=c4d.DLG_TYPE_ASYNC,pluginid=PLUGIN_ID, defaultw=100, defaulth=100,subid=SUB_DIALOG_ID)



            return True

    def Restore(self, pluginid, secret):
        if secret['subid'] == SUB_DIALOG_ID:
            return self.sub_dialog.Restore(pluginid, secret)
        else:
            return super(S_Lib_Dialog, self).Restore(pluginid, secret)






class S_Lib(plugins.CommandData):

    dialog = None

    def Execute(self,doc):
        # create the dialog
        if self.dialog is None:
            self.dialog = S_Lib_Dialog()

        return self.dialog.Open(dlgtype=c4d.DLG_TYPE_ASYNC, pluginid=PLUGIN_ID, defaultw=800, defaulth=400)

    def RestoreLayout(self, sec_ref):
        # manage nonmodal dialog
        if self.dialog is None:
            self.dialog = S_Lib_Dialog()

        return self.dialog.Restore(pluginid=PLUGIN_ID, secret=sec_ref)


# Execute main()
if __name__=='__main__':
    path, fn = os.path.split(__file__)
    plugins.RegisterCommandPlugin(id=PLUGIN_ID,
                                  str="test command",
                                  info=0,
                                  help="",
                                  dat=S_Lib(),
                                  icon=None)

test tool plugins code:

import c4d
import os

from c4d import gui, plugins, bitmaps

PLUGIN_ID = 1000010 #only for test


def GetSafeWindow_Center():
    doc = c4d.documents.GetActiveDocument()
    bd = doc.GetActiveBaseDraw()
    window_dict = bd.GetFrame()

    window_l = window_dict['cl']
    window_r = window_dict['cr']
    window_t = window_dict['ct']
    window_b = window_dict['cb']



    return bd, window_l, window_r, window_t, window_b


def Draw2dbox(bd, x_min, x_max, y_min, y_max):
    p1 = c4d.Vector(x_min, y_min, 0)
    p2 = c4d.Vector(x_max, y_min, 0)
    p3 = c4d.Vector(x_max, y_max, 0)
    p4 = c4d.Vector(x_min, y_max, 0)
    bd.DrawLine2D(p1, p2)
    bd.DrawLine2D(p2, p3)
    bd.DrawLine2D(p3, p4)
    bd.DrawLine2D(p4, p1)


def DrawBox(width_height, offset=c4d.Vector(0, 0, 0), color=c4d.Vector(1, 0, 0)):
    # draw box

    bd, safe_window_l, safe_window_r, safe_window_t, safe_window_b = GetSafeWindow_Center()

    safe_center = ((safe_window_r + safe_window_l) / 2 + offset[0], (safe_window_b + safe_window_t) / 2 + offset[1])

    #
    width_half = width_height[0] / 2
    height_half = width_height[1] / 2

    x_min = safe_center[0] - width_half
    x_max = safe_center[0] + width_half
    y_min = safe_center[1] - height_half
    y_max = safe_center[1] + height_half

    #
    bd.SetMatrix_Screen()
    bd.SetPen(color)
    bd.DrawPoint2D(c4d.Vector(safe_center[0], safe_center[1], 0))
    Draw2dbox(bd, x_min, x_max, y_min, y_max)

class S_ScreenShot_Dialog(gui.SubDialog):
    parameters = None

    def __init__(self, para_in):
        self.parameters = para_in

    def update(self,command=False):
        if command:
            #update gui parameter
            if self.parameters['path']:
                self.SetString(1012,self.parameters['path'])
            if self.parameters['name']:
                self.SetString(1014,self.parameters['name'])


    def Command(self,id,msg):

        if id == 1033:
            return True
        if id == 1022 or id == 1032:
            #
            self.parameters['width'] = self.GetInt32(1022)
            self.parameters['height'] = self.GetInt32(1032)
            c4d.DrawViews(c4d.DRAWFLAGS_ONLY_BASEDRAW)
            return True

        if id == 1021:
            #
            self.SetInt32(1032, self.GetInt32(1022))
            self.parameters['width'] = self.GetInt32(1022)
            self.parameters['height'] = self.GetInt32(1032)
            c4d.DrawViews(c4d.DRAWFLAGS_ONLY_BASEDRAW)
            return True

        if id == 1031:
            #
            self.SetInt32(1022, self.GetInt32(1032))
            self.parameters['width'] = self.GetInt32(1022)
            self.parameters['height'] = self.GetInt32(1032)
            c4d.DrawViews(c4d.DRAWFLAGS_ONLY_BASEDRAW)
            return True

        if id == 1051:
            #
            self.parameters['offset'] = c4d.Vector(0)
            c4d.DrawViews(c4d.DRAWFLAGS_ONLY_BASEDRAW)
            return True
        if id == 1012:
            #
            self.parameters['path'] = self.GetString(1012)
            return True

        if id == 1034:
            #
            self.parameters['showbmp'] = self.GetBool(1034)
            return True

        return True

    def CreateLayout(self):
        self.GroupBegin(1010, c4d.BFH_SCALEFIT, 2, 1)
        self.GroupBorderSpace(10, 10, 10, 10)
        self.AddStaticText(1011, c4d.BFH_MASK, initw=50, inith=0, name="Path:")
        bc = c4d.BaseContainer()
        bc.SetBool(c4d.FILENAME_DIRECTORY,True)
        self.AddCustomGui(1012, c4d.CUSTOMGUI_FILENAME,"",c4d.BFH_SCALEFIT, 50, 20, bc)
        self.AddStaticText(1013, c4d.BFH_MASK, initw=50, inith=0, name="Name:")
        self.AddEditText(1014,c4d.BFH_MASK, initw=200, inith=0)

        self.GroupEnd()
        self.GroupBegin(1020, c4d.BFH_SCALEFIT, 2, 1)
        self.GroupBorderSpace(10, 10, 10, 10)

        self.GroupBegin(1100, c4d.BFH_SCALEFIT, 2, 1)
        self.AddButton(1021, c4d.BFH_MASK, initw=0, inith=0, name="Width:")
        self.AddEditNumberArrows(1022, c4d.BFH_MASK, initw=70, inith=0)
        self.AddButton(1031, c4d.BFH_MASK, initw=0, inith=0, name="Height")
        self.AddEditNumberArrows(1032, c4d.BFH_MASK, initw=70, inith=0)
        self.GroupEnd()
        self.AddButton(1051, c4d.BFH_LEFT, initw=100, inith=20, name="Center")

        self.GroupEnd()
        self.AddButton(1033, c4d.BFH_MASK, 100, 20, "Cut")
        self.AddCheckbox(1034,c4d.BFH_LEFT,100,10,"Show In Picture View ")

        return True

    def InitValues(self):
        self.SetInt32(1022, self.parameters['width'])
        self.SetInt32(1032, self.parameters['height'])
        self.SetBool(1034,self.parameters['showbmp'])
        if self.parameters['path']:
            self.SetString(1012, self.parameters['path'])

        return True













class S_ScreenShot(plugins.ToolData):
    subdialog = None
    def __init__(self):
        self.data = {'width':512,'height':512,'offset':c4d.Vector(0),'path':'','name':'','showbmp':False}
        self.subdialog = S_ScreenShot_Dialog(self.data)

        #self.last_offset = c4d.Vector(0)

    def set_para_self(self,data):
        #
        if data[1]:
            self.data['path'] = data[1]  # path
        if data[2]:
            self.data['name'] = data[2]  # name


    def Message(self,doc, data, type, t_data):
        if type == PLUGIN_ID:
            #get commanddata plugins message
            self.set_para_self(data)
            # update tool gui parameter
            self.subdialog.update(True)
            return True

        return True
    def Draw(self, doc, data, bd, bh, bt, flags):
        DrawBox((self.data['width'],self.data['height']), self.data['offset'])
        return c4d.TOOLDRAW_NONE

    def MouseInput(self, doc, data, bd, win, msg):

        mx = msg[c4d.BFM_INPUT_X]
        my = msg[c4d.BFM_INPUT_Y]

        device = 0
        #print msg[c4d.BFM_INPUT_CHANNEL],c4d.BFM_INPUT_MOUSELEFT,c4d.BFM_INPUT_MOUSERIGHT,c4d.BFM_INPUT_MOUSEMIDDLE
        if msg[c4d.BFM_INPUT_CHANNEL] == c4d.BFM_INPUT_MOUSELEFT:
            device = c4d.KEY_MLEFT
        elif msg[c4d.BFM_INPUT_CHANNEL] == c4d.BFM_INPUT_MOUSERIGHT:
            device = c4d.KEY_MRIGHT
        elif msg[c4d.BFM_INPUT_CHANNEL] == c4d.BFM_INPUT_MOUSEMIDDLE:
            device = c4d.KEY_MMIDDLE
        else:
            return True

        dx = 0.0
        dy = 0.0

        win.MouseDragStart(button=device, mx=int(mx), my=int(my),
                           flags=c4d.MOUSEDRAGFLAGS_DONTHIDEMOUSE | c4d.MOUSEDRAGFLAGS_NOMOVE)
        result, dx, dy, channel = win.MouseDrag()

        while result == c4d.MOUSEDRAGRESULT_CONTINUE:
            mx += dx
            my += dy


            # continue if user doesnt move the mouse anymore
            if dx == 0.0 and dy == 0.0:
                result, dx, dy, channel = win.MouseDrag()
                continue


            if msg[c4d.BFM_INPUT_QUALIFIER] & c4d.QSHIFT:

                self.data['offset'] = c4d.Vector(dx, dy, 0) + self.data['offset']

            if msg[c4d.BFM_INPUT_QUALIFIER] & c4d.QCTRL:
                #
                scale = dx * 0.0005 + 1.0
                self.data['width'] *= scale
                self.data['height'] *= scale
                self.subdialog.update()
            #set camera parameter
            c4d.DrawViews(c4d.DA_ONLY_ACTIVE_VIEW | c4d.DA_NO_THREAD)



            result, dx, dy, channel = win.MouseDrag()


        return True

    def AllocSubDialog(self, bc):
        self.subdialog = S_ScreenShot_Dialog(self.data)
        return self.subdialog #always return new instance







if __name__ == "__main__":
    dir, file = os.path.split(__file__)
    plugins.RegisterToolPlugin(id=PLUGIN_ID, str="tool_test",
                               info=0, icon=None,
                               help="",
                               dat=S_ScreenShot())

This is the screen recording of the crash of the above code example:

Hi,
i use a CommandData plugins to creat a button to active my tool plugins,and use tool.Message(123) to pass messages to tool plugins and refresh the gui parameters of tool plugins.
In practice it is：
When I click the button, the tool is activated, and some str parameters of the tool are set, and then the changed parameters are displayed. As shown below image1, I will set some strings to these 2 gui elements

image1:

Here's a screen recording showing c4d crashing：

I tried to find the reason, I found that c4d does not crash when I activate the tool by click button, without setting the parameters of the tool！

two plugins use python!
Thanks for any help!

Hi,
i read python sdk BaseContainer.FindIndex() return a bool but actually return a dict

@ferdinand Thanks!

Hi,
Use MenuInitString() change checked/unchecked state of menu item,
how to get checked/unchecked state?
Thanks for any help!

@ferdinand Thanks!
